robatherm RM Series - Heat Pipe; Commissioning and Inspection

Commissioning and Maintenance
46 © robatherm
Pos: 60.1 /Überschri ften/__Wärmerohr- WRG @ 0\mod_1257341712576_2 008.doc @ 2049 @ 2
Heat Pipe
Pos: 60.2 /Inbetri ebnahme und Wartung/_Inbe triebnahme @ 0\mod_12579 29574289_2008.doc @ 2116 @ 3
Commissioning
Pos: 60.3 /Sicher heitshinweise/!Vor sicht_Sicherheitshi nweise beachten_Quer verweis @ 0\mod_125777 7093652_2008.doc @ 2112 @
Caution
Observe general safety instructions on page 3!
Pos: 60.4 /Inbetri ebnahme und Wartung/W ärmerohr-WRG/Wärmerohr -WRG_Prüfung @ 0\mod_125 8443318168_2008.doc @ 2189 @ 4
Inspection
Check (and clean if necessary) heat pipe for foreign particles and contamination (see below).
Pos: 60.5 /Inbetri ebnahme und Wartung/_W artung @ 0\mod_125792958525 7_2008.doc @ 2117 @ 3
Maintenance
Pos: 60.6 /Inbetri ebnahme und Wartung/W artungsintervall_3Mona te/ATEX monatlic h @ 0\mod_1257930528679_20 08.doc @ 2122 @ 4
Maintenance Interval
Every three months. ATEX units every month.
Pos: 60.7 /Sicher heitshinweise/!Vor sicht_Sicherheitshi nweise beachten_Quer verweis @ 0\mod_125777 7093652_2008.doc @ 2112 @
Caution
Observe general safety instructions on page 3!
Pos: 60.8 /Sicherheitshinweise/IBN&Wartung/!IBN&Wartung_Wärmerohr-W RG_Vorsicht @ 0\mod_1258443402 736_2008.doc @ 2190 @
Caution
There is a danger to life when charging gas under high pressure! Do not damage or
overheat pipes (e.g. by means of welding torch).
Pos: 60.9 /Inbetri ebnahme und Wartung/W ärmerohr-WRG/Wärmerohr -WRG_Wartung @ 0\mod_12584 43481790_2008.doc @ 2191 @
Heat Pipe-HRS – Periodic Maintenance
 Check heat pipe for hygiene, contamination, damage and corrosion
 Check water outlet and siphon function, clean if necessary
 Check water level of siphon, top up if necessary
Heat Pipe-HRS – Maintenance when necessary
 Clean the heat pipe on the air side (see below), rectify damage and corrosion
Pos: 60.10 /Inbetri ebnahme und Wartung/W ärmerohr-WRG/Wärmerohr -WRG_Reinigung @ 0\mod_1258 443605956_2008.doc @ 2192 @ 44
Cleaning
Observe the following points:
 Avoid bending plate fins.
 Blow out with compressed air in the opposite direction.
 Do not use a high pressure cleaner or a high pressure steam cleaner.
 Clean with water and low pressure.
Cleaning Agents
Use cleaning agents with a pH-value between 7 and 9 if required.
