Commissioning and Maintenance
© robatherm 19
Pos: 39 /Überschrif ten/_Inbetriebnahm e und Wartung @ 0\mod_1256570 167929_2008.doc @ 2011 @ 1
Pos: 40.1 /Überschri ften/__Gliederk lappe @ 0\mod_1257341369 525_2008.doc @ 2041 @ 2
Damper
Pos: 40.2 /Inbetri ebnahme und Wartung/_Inbe triebnahme @ 0\mod_12579 29574289_2008.doc @ 2116 @ 3
Commissioning
Pos: 40.3 /Sicher heitshinweise/!Vor sicht_Sicherheitshi nweise beachten_Quer verweis @ 0\mod_125777 7093652_2008.doc @ 2112 @
Caution
Observe general safety instructions on page 3!
Pos: 40.4 /Sicherheitshinweise/IBN&Wartung/!IBN&Wartung_Gliederklappe_I BN_Vorsicht @ 0\mod_12579 29842885_2008.doc @ 2118 @
Caution
Do not grip into damper as there is a danger of crushing to limbs! Protection devices such
as e.g. duct connection, protective grille etc. must be present in accordance with DIN EN
ISO 12100.
Pos: 40.5 /Sicherheitshinweise/IBN&Wartung/!IBN&Wartung_Gliederklappe_I BN_ATEX @ 0\mod_12579299 77593_2008.doc @ 2119 @
Only use approved actuators with ATEX units. All electrical parts must be earthed.
Pos: 40.6 /Sicherheitshinweise/IBN&Wartung/!IBN&Wartung_Gliederklappe_I BN_Achtung @ 0\mod_12579 30080991_2008.doc @ 2120 @
Attention
Do not switch on fan before checking that the appropriate damper is open or that its
opening is indicated by a position switch Provide a control linkage so that when a damper
closes, the fans affected are switched off immediately.
robatherm accepts no liability for damage due to incorrect operation.
Provide pressure relief dampers to prevent damage from pressure spikes due to fire
dampers in the system.
Pos: 40.7 /Inbetri ebnahme und Wartung/Glieder klappe/Glieder klappe_IBN @ 0\mod_1257 930172641_2008.doc @ 2121 @ 44
Coupled Dampers
If dampers are coupled, check friction locking and proper functioning linkage, i.e. direction of
rotation and end position of dampers.
Check for proper tightening of all screws and connections.
Motor Driven Dampers
For drive by servo motor: Set linkage so that there is a rotational angle of 90 degrees and
the dampers reach their end position on closing.
Pos: 40.8 /Inbetri ebnahme und Wartung/_W artung @ 0\mod_125792958525 7_2008.doc @ 2117 @ 3
Maintenance
Pos: 40.9 /Inbetri ebnahme und Wartung/W artungsintervall_3Mona te/ATEX monatlic h @ 0\mod_1257930528679_20 08.doc @ 2122 @ 4
Maintenance Interval
Every three months. ATEX units every month.
Pos: 40.10 /Sicher heitshinweise/!Vor sicht_Sicherheits hinweise beachten_ Querverweis @ 0\mod_12577 77093652_2008.doc @ 2112 @
Caution
Observe general safety instructions on page 3!
Pos: 40.11 /Sicherheitshinweise/IBN&Wartung/!IBN&Wartung_Gliederklappe_IB N_Vorsicht @ 0\mod_1257 929842885_2008.doc @ 2118 @
Caution
Do not grip into damper as there is a danger of crushing to limbs! Protection devices such
as e.g. duct connection, protective grille etc. must be present in accordance with DIN EN
ISO 12100.
Commissioni
ng and
Maintenance
