Hydraulic Set
Pos: 76.2 /Inbetri ebnahme und Wartung/_Inbe triebnahme @ 0\mod_12579 29574289_2008.doc @ 2116 @ 3
Commissioning
Pos: 76.3 /Sicher heitshinweise/!Vor sicht_Sicherheitshi nweise beachten_Quer verweis @ 0\mod_125777 7093652_2008.doc @ 2112 @
Caution
Observe general safety instructions on page 3!
Pos: 76.4 /Sicherheitshinweise/IBN&Wartung/!IBN&Wartung_Vorsicht_Mediu m mit Umgebungstemperatur @ 0\mod_1258374559693_2 008.doc @ 2161 @
Caution
Only use fluid with ambient temperature when charging or purging as there is a risk of
scalding/frostbite.
Pos: 76.5 /Sicherheitshinweise/IBN&Wartung/!IBN&Wartung_Vorsicht_heiße/ kalten Flächen @ 0\mod_12 58374632300_2008. doc @ 2162 @
Caution
To avoid burns, do not touch hot/cold surfaces.
Pos: 76.6 /Sicherheitshinweise/IBN&Wartung/!IBN&Wartung_ATEX-Bauteile erden @ 0\ mod_1257956926546_2 008.doc @ 2126 @
Only use approved parts with ATEX units. All electrical parts must be earthed.
Pos: 76.7 /Sicherheitshinweise/IBN&Wartung/!IBN&Wartung_Hydraulische Regel gruppe_IBN_ATEX @ 0\mod_12 58546300982_2008. doc @ 2251 @
Ensure sufficient distance between max. surface temperature of the heat exchanger due to
temperature of the medium and minimum ignition temperature of any flammable mixture
which may be present in accordance with EN 1127.
Pos: 76.8 /Sicherheitshinweise/IBN&Wartung/!IBN&Wartung_Hydraulische Regel gruppe_IBN_Achtu ng @ 0\mod_1258546384854_ 2008.doc @ 2252 @
Attention
Do not exceed permissible pressure range.
Observe design data sheet.
In HRS control equipment (e.g. run around coils heat recovery system) the quantity of anti-
freeze is to be determined in relation to the lowest outside temperature (note
manufacturer’s information).
Pos: 76.9 /Inbetri ebnahme und Wartung/Hydr aulische Regelgrupp e/Hydraulische Rege lgruppe_Prüfungen @ 0\ mod_1258546078597_200 8.doc @ 2250 @ 4444
Inspections
Check:
Correct installation of all components.
Inlet outlet connections for function (counter flow principle).
Firm seating of all bolts and glands.
Easy movement of all valves, slide dampers and baffles.
Charging
The system must be rinsed (removal of contaminations) according to VDI 2035 and should
be filled with the heat exchanger fluid named in the design data sheet to the correct
concentration. Water quality to VDI 2035. This control equipment charging process can also
occur together with the charging of the piping system. During charging check connection
points for leakage; retighten screws and glands if necessary.
Venting
When charging the system according to VDI 2035 the control equipment and the system
should be vented carefully at the highest point of the system. Open the venting recovery
device provided for this purpose. This is also valid for pumps with venting devices (e.g. high
pressure centrifugal pumps in high efficiency run around heat recovery systems). Observe
manufacturer’s instructions.
In incompletely vented systems with pumps, air pockets may cause capacity reduction and
severe damages of the pump.
