Robe iForte - Page 37

37
Pan Min. Value - Minimum pan movement value.
Pan Max. Value - Maximum pan movement value.
Tilt Min. Value - Minimum tilt movement value.
Tilt Max. Value - Maximum pan movement value.
If receiving DMX values are out of set limits, the xture will not respond to them.
Example: Pan Min. Value=40 DMX, Pan Max. Value=120 DMX, the head will move in pan range of 40-120
DMX. Values under 40 and above 120 will not be used.
At reset of the head without connected DMX (if Pan/Tilt brake=O󰀨), the pan movement of the head will stop in
the value 120 DMX. After cancelling the pan movement limitation, the head will move to the value 128 DMX .
(Standard pan and tilt positions after reset of the head without DMX are 128 DMX, unless otherwise set in the
menu Init Positions).
Blackout Settings - Use the menu if you need to close the light output under certain conditions which are
described below
Blackout During MC - Blackout during movement correction. Set this option On if you wish to close light
output during the time when the head goes to its correct position from which has been changed by an
external force.
Active Blackouts - Use this menu if you wish to close the light output during e󰀨ect changes.
Pan/Tilt Moving - The menu item enables you to close light output while the pan/tilt DMX
values are changing.
Colour Wheel Moving - The menu item enables you to close light output while colour wheel
is moving.
Gobo Wheel Moving - The menu item enables you to close light output while the gobo wheel
is moving.
Frequency Setup - The function allows you to set the PWM (Pulse Width Modulation) output frequency of
LEDs to 300Hz, 600Hz, 1200Hz or 2400Hz.
Frequency Adjust - The menu item allows you ne adjustment of the LED frequency around selected frequency.
Init E󰀨ect Positions - Use the menu to set all e󰀨ects to the desired positions at which they will stay after
switching the xture on without DMX signal received.
Screen Settings - Use this menu to change the touch screen settings.
Display Intensity - The item allows to control the intensity of the screen (1-min., 10-max.).
Screen saver Delay - The item allows you to keep the screen on or to turn it o󰀨 automatically after 1-10
minutes after last touch (or pressing any button on the control panel).
Touchscreen Lock - The item allows you to lock the screen after last touch (or pressing any button on the
control panel). The time delay can be set in range of 1-10 minutes.To unlock the screen, press the
[ENTER/Display On] button.
Recalibrate Touchscreen - The item starts calibration of the touch screen. Follow the instructions on
the screen.
Display Orientation - The menu allows to change display orientation.
Normal - Standard display orientation if the xture is placed horizontally (e.g. on the ground).
Inverted - Inverted orientation (needed if the xture is hanging on the truss).
Auto - The option activates a gravitation sensor for automatic screen orientation.
Note: Auto option is set as default. You change the display orientation by touching the icon on the display,
an the option set in the "Display Orientation" menu is temporarily overridden.
Temperature unit - Use the menu item to change temperature unit from °C to °F.
Fan Settings - Use the menu to set fans operation mode.
Fan Mode - Use the menu to set the xture fans to max. power mode (option "High") or to
the auto-control mode (option "Auto"). The option "Quiet" allows you to set desired fan noise.
The light output of the xture is reduced at low speeds of fans. Last option "Super Quiet" provides
extremely quiet operation of the xture.
Quiet - Blackout Fan O󰀨 - The menu item allows you to stop all fans in the xture (option "On")
when its light output is closed (shutter in range of 0-31 DMX or dimmer in 0 DMX).
Dimmer Curve - Use the menu to select desired dimmer curve: Linear, Square Law or Super Square Law.
Gobo Indexing - The following three options dene transition from gobo rotation to gobo indexing.
Max. Speed & Shortcut - Gobo goes from its rotation to desired indexed position with max. speed and
via shortest track.
Follow Speed & Direction - Gobo goes from its rotation to desired indexed position with current speed
