Robe iForte - Changing the LED Light Source

57
14.3 Changing the LED light source
The Robin Forte allows you to change the LED light source and this way keep a high performance of the xture.
Unplug the xture from mains before replacing LED light source!
Do not change LED light source in a damp environment (e.g. rain, snowfall)!
To change the LED light source.
1. Disconnect the xture from mains and allow it to cool about 60 minutes.
2. Lock the head in a horizontal position.
3. Remove the rear cover (1) of the xture head by unscrewing two screws M5x20 (2) on each side of the cover.
4. Unscrew the four screws M6x25 (4) and the four screws M5x14 (5) and remove the LED light source (6) from
the head. Be careful, the LED light source is heavy.
1
2
2
6
4 4
4
4
5
5
