DMX protocol
1 2
42 44 0
43 45 128
44 46 0
45 47 128
46 48 0
47 49 128
48
50
0
49 51 128
50 52 0
51 53 128
52 54 32
53 55 0
54 56 0
1 2
1 1
Pan
0 - 255 Pan movement by 540° (128=default) proportional
2 2
Pan Fine
0 - 255 Fine control of pan movement (0=default) proportional
3 3
Tilt
0 - 255 Tilt movement by 270° (128=default) proportional
4 4
Tilt fine
0 - 255 Fine control of tilt movement (0=default) proportional
5 5
Pan/Tilt speed , Pan/Tilt time
0 Standard mode (0=default) step
1 Max. Speed Mode step
Pan/Tilt speed mode
2 - 255 Speed from max. to min. proportional
Pan/Tilt time mode
2 - 255 Time from 0.2 sec. to 25.5 sec. proportional
6 6
Power/Special functions
Factory display menu setting: DMX Input-Wired ,Graphic display-
On, Pan/tilt Mode-Speed,Blackout while pan/tilt moving-Off,
Blackout while gobo wheels moving-Off,Blackout while colour
wheels moving-Off, Fans mode-Auto, High-power mode Off , Quiet
mode: Fans Off at blackout,
0 -5 Reserved (0=default)
To activate following functions, stop in DMX value for at least 3 s and
shutter must be closed at least 3 sec. (Channel „Shutter/ Strobe” 52/54
must be at range: 0-31 DMX). Corresponding menu items are temporarily
overridden except DMX input .
6-7
Standby mode: On (fixture effects are deactivated, light output is
closed)
step
8-9
Standby mode: Off
step
10-14
DMX input: Wired DMX *
step
15-19
DMX input: Wireless DMX *
step
* function is active only 10 seconds after switching the fixture on
Dimmer intensity - fine
Mode/Channel
DMX
Value
Function
Type of
control
Dimmer intensity
Focus - fine
Framing shutters module rotation
Framing shutter 1- movement
Framing shutter 1- swivelling
Framing shutter 2- movement
Framing shutter 2- swivelling
Framing shutter 3 movement
Framing shutter 3- swivelling
Framing shutter 4 movement
Framing shutter 4- swivelling
Shutter/ strobe
Mode/Channel
Default
DMX Value
Function
