DMX protocol
1 2
Mode/Channel
DMX
Value
Function
Type of
control
0-255 Speed of CMY+CTO movement from max. to min. (0=default) proportional
0-255 Speed of Rot. Gobos selection from max. to min. proportional
21 21
CMY+CTO+Colour wheels time
0 Function is off (0=default) step
1 - 255 Time of CMY, CTO and Colour wheels movement (0.1sec-->25.5sec.) proportional
22 22
Framing shutters/Zoom/Focus/Iris/Frost/Prism time
0 Function is off (0=default) step
1 - 255
Time of framing shutters, zoom, focus, iris and frost movement (0.1
sec-->25.5 sec.)
proportional
1-50
Time of prism movement (0.1 sec-->5 sec.)
proportional
23 23
Effect wheel positioning
0-19 No function (0=default) step
20-127 Proportional indexing (73-center) proportional
128-170 Ramping from open to full position ( max--->min. speed) proportional
171-213 Ramping from open to half position ( max. --->min. speed) proportional
214-255 Ramp. from half position to full position ( max. --->min. speed) proportional
24 24
Effect wheel rotation
0 No rotation step
1 - 127 Forwards rotation from fast to slow proportional
128 No rotation (128=default) step
129 - 255 Backwards rotation from slow to fast proportional
25 25
Effect wheel animations
0-7 No animation (0=default)
Note :
Set suitable DMX value at
Focus
channel to get desired
animation. All animations were created at distance of 5 m from screen
with zoom=128 DMX, Focus value is different for each effect (focus value is
stated in parentheses for this distance)
The following channels are blocked: Effect wheel positioning, Effect
wheel rotation, Rotating gobo wheel 1/2, Rot. Gobo 1/2 indexing and
rotation, Rot. Gobo wheel 1/2 fine rotation.
8-9 Macro 1 (Focus=190) step
10-11 Macro 2 (Focus=167) step
12-13 Macro 3 (Focus=170) step
14-15 Macro 4 (Focus=170) step
16-17 Macro 5 (Focus=170) step
18-19 Macro 6 (Focus=136) step
20-21 Macro 7 (Focus=140) step
22-23 Macro 8 (Focus=130) step
24-25 Macro 9 (Focus=142) step
26-27 Macro 10 (Focus=140) step
28-255 Reserved
26 *
Rotating gobo wheel 1
Index - set indexing on channel 27
0-4 Open/hole (0=default) step
5-8 Gobo 1 step
9-13 Gobo 2 step
14-17 Gobo 3 step
18-22 Gobo 4 step
23-26 Gobo 5 step
