DMX protocol
1 2
Mode/Channel
DMX
Value
Function
Type of
control
128 0 degrees (128=default) step
129-255 Swivelling from 0 degrees to +30 degrees proportional
50 52 Framing shutter 4 movement
0-255 Movement from Outward to Inward (0=default) proportional
51 53 Framing shutter 4- swivelling
0-127 Swivelling from -30 degrees towards 0 degrees proportional
128 0 degrees (128=default) step
129-255 Swivelling from 0 degrees to +30 degrees proportional
52 54
Shutter/ strobe
0 - 31 Shutter closed step
32 - 63 Shutter open (32=default) step
64 - 95 Strobe-effect from slow to fast proportional
96 - 127 Shutter open step
128 - 143 Opening pulse in sequences from slow to fast proportional
144 - 159 Closing pulse in sequences from fast to slow proportional
160 - 191 Shutter open step
192 - 223 Random strobe-effect from slow to fast proportional
224 - 255 Shutter open step
53 55
Dimmer intensity
0 - 255 Dimmer intensity from 0% to 100% (0=default) proportional
54 56
Dimmer intensity - fine
0 - 255 Fine dimming (0=default) proportional
