3.2. DESCRIPTION OF THE OPERATION CYCLE
Phase 1
The operator loads the pallet on the rotary table and
fastens the film in the relevant locking disc (if any), or to
the pallet corner.
Caution - warning
Risk of crushing upper limbs.
Do not insert the film in the gripper by hand.
Phase 2
Once the cycle has started, the rotary table starts to turn,
while the film carriage unwinds the film for the entire
height, according to pre-set parameters.
Phase 3
Once the wrapping phase has ended, the machine stops
for manual film cutting.
Phase 4
The operator unloads the pallet.
The cycle is complete and the machine is ready to start
a new cycle.
