6.2. DESCRIPTION OF CONTROLS (ECOPLAT PLUS BASE)
A) Emergency stop button:
it is used in case of imminent risk to stop, with a voluntary action, the machine parts which may pose a risk.
For further details, see the paragraph “description of safety devices”.
B) “Cycle start” button:
it is used to start the wrapping automatic cycle.
The button indicator light on indicates that the electrical power supply is activated.
C) “Cycle stop” button:
it is used to stop the wrapping automatic cycle.
D) “Upper and lower wrapping” selector:
used to set the number of wraps (upper and lower) to be performed on the pallet.
- D0: no wrapping.
- D1: one wrapping on the top and bottom.
- D2: two wrappings on the top and bottom.
- D3: reinforcing wrapping
When the selector is set to position “D3”, the film carriage stops to allow reinforcing wrapping to be performed.
As long as the selector remains in position “D3”, wrapping is performed in the same point.
Set the selector to one of the “D0-D1-D2” positions to restart the film carriage.
E) Carriage "upstroke/downstroke speed” button:
used to set the film carriage upstroke and downstroke speed while the carriage is in motion.
- Pressed on (E1), the button decreases film carriage speed.
- Pressed on (E2), the button increases film carriage speed.
- If either buttons (E1 - E2) are pressed together with button (C), they move the film carriage (in “manual”
mode).
F) “Table rotation speed” button:
used to set to table rotation speed, with the rotary table in motion.
- Pressed on (F1), the button decreases table rotation speed.
- Pressed on (F2), the button increases table rotation speed.
- Pressing key (F2) together with button (C) (Stop button) allows moving the table (in “manual mode”).
G) “Reset” button:
it is used to reset the machine before restarting it after an emergency stop or after a shut-down due to the
disconnection of the power supply.
H) Emergency override key-operated switch:
it is used to temporarily bypass the carriage emergency.
When the key is turned to the “I” position (hold to run), the “start” button (B) lights up. When the “start” button
(B) is pressed, the carriage is raised.
J) USB port:
used to update the machine software.
If a USB flash drive containing updated software is inserted into the port, the software will be installed on the
machine when it is turned on.
K) Main disconnector:
it enables and disables the power supply.
- Pos. “O”: power supply off.
- Pos. “I”: power supply on.
