6.3. DESCRIPTION OF CONTROLS (ECOPLAT PLUS FRD)
A) Emergency stop button:
it is used in case of imminent risk to stop, with a voluntary action, the machine parts which may pose a risk.
For further details, see the paragraph “description of safety devices”.
B) “Cycle start” button:
it is used to start the wrapping automatic cycle.
C) “Cycle stop” button:
it is used to stop the wrapping automatic cycle.
D) Multi-function selector:
it allows activating and setting machine functions.
Turn the selector (clockwise or counter-clockwise) until the LED for the desired function turns on.
E) Digital display:
it shows the working parameters and alarm codes.
F) Machine functions:
- F1-F8: these are the various functions available on the machine (see the “Machine functions” section).
G) “Reset” button:
it is used to reset the machine before restarting it after an emergency stop or after a shut-down due to the
disconnection of the power supply.
H) Emergency override key-operated switch:
it is used to temporarily bypass the carriage emergency.
When the key is turned to position “I” (hold to run), the user interface screen will display the page “emergency
override” and this allows the carriage alone to be lifted by pressing the “multi-function selector” (D).
J) USB port:
used to update the machine software.
If a USB flash drive containing updated software is inserted into the port, the software will be installed on the
machine when it is turned on.
K) Main disconnector:
it enables and disables the power supply.
- Pos. “O”: power supply off.
- Pos. “I”: power supply on.
