INFORMATION ABOUT THE USE
6.5. “MANUAL HANDLING” PAGE
The page displays the controls to activate the spool carriage vertical movement in “manual mode”.
Button (hold to run): it is used to activate the carriage upstroke.
Button (hold to run): it is used to activate the carriage downstroke.
Button (hold to run): it is used to activate the table clockwise rotation.
Button (hold to run): it is used to activate the table counter-clockwise rotation.
Button (hold to run): it is used to activate the presser arm upstroke.
Button (hold to run): it is used to activate the presser arm downstroke.
Button (hold to run): it is used to activate the creasing head upstroke.
Button (hold to run): it is used to activate the creasing head downstroke.
Button (hold to run): it is used to activate the punch forward movement.
Button (hold to run) it is used to activate the carriage return and the table synchronisation.
Button: it is used to display the “home” page.
