Robustel GoRugged R2000 User Manual

Robustel GoRugged R2000 User Guide
RT_UG_R2000_v.1.2.0 15.12.2015 15 /120
Confidential
2.2 LED Indicators
Note: User can select display status of USR LED. For details please refer to 3.20 Service->Advanced section.
Name
Color
Status
Function
RUN
Green
Blinking
Router is ready.
On
Router is starting.
Off
Router is power off.
PPP
Green
Blinking
PPP Indicator: Null
On
PPP Indicator: PPP connection is up.
Off
PPP Indicator: PPP connection is down.
USR
Green
Blinking
SIM: using backup SIM card.
NET: register to a low level network.
Off after blinking
SIM: working fine.
NET: working fine.
Light up
OpenVPN: OpenVPN is connected.
IPSec: IPSec is connected.
GRE: GRE is connected.
Off after lighting up
OpenVPN: OpenVPN is disconnected.
IPSec: IPSec is disconnected.
GRE: GRE is disconnected.
Green
On
Signal level: 21-31 (Perfect signal level).
Yellow
On
Signal level: 11-20 (Average signal level).
Red
On
Signal level: 1-10 (Exceptional signal level).
When the network is disconnected, those three signal LEDs are designed as a binary combination code to
indicate a series of error report.
(Green Yellow Red) On: 1 Off: 0
001 AT command failed
010 no SIM card detected
011 it need to enter the PIN code
100 it need to enter the PUK code
101 registration failed
110 something wrong happened in the module

Robustel GoRugged R2000 Specifications

General

Model	GoRugged R2000
Category	Network Router
Ethernet Ports	2 x 10/100 Mbps
SIM Slots	2
Power Supply	9-36 VDC
USB Port	1 x USB 2.0
Cellular Connectivity	4G LTE, 3G
VPN Support	IPsec, OpenVPN, GRE
Operating Temperature	-40°C to +75°C
WiFi	802.11 b/g/n
Serial Interface	RS232/RS485
GPS	Yes
Firewall	SPI Firewall
Digital Input/Output	2 x DI
