3.8 Interface->Ethernet
This section allow user to set the parameter of the Ethernet port. One port should be assigned to lan0 a least.
Click button, configure the port setting.
Ethernet
Item
Description
Default
Index
The index of Ethernet port, cannot edit.
1 or 2
Port
eth0 or eth1
One port should be assigned to lan0 a least.
/
Port Assignment
Select lan0 or lan1.
Note: When eth0 used As WAN, lan1 is unavailable. Please go to System->Device
Configuration to enable eth0 used as WAN.
And lan1 available only if it was selected by eth0 or eth1 in this field.
lan0
3.9 Interface->Cellular
This section allows users to set the Cellular WAN and the related parameters.
When it is the first time to insert single SIM card, SIM card 1 and SIM card 2 slots are available.
SIM
