enable the Data Allowance function in Link Manager->Link Setting->WWAN Setting.
3.7 Interface->LAN
This section allows user to set the LAN and the related parameters.
LAN
Click to edit the configuration of the current LAN interface. Click to delete the current LAN interface.
Click to add a new LAN interface. The maximum number of LAN interface is two.
General Settings
Item
Description
Default
Interface
Select lan0 or lan1.
When eth0 used As WAN, lan1 is unavailable.
And lan1 available only if it was selected by eth0 or eth1 in
Ethernet->Port Setting section.
lan0
IP Address
Set the IP Address of the LAN interface.
192.168.0.1
Netmask
Set the Netmask of the LAN interface.
255.255.255.0
MTU
Maximum Transmission Unit. It is the identifier of the maximum
size of packet, which is possible to transfer in a given environment.
1500
