Robustel GoRugged R2000 User Manual

Robustel GoRugged R2000 User Guide
RT_UG_R2000_v.1.2.0 15.12.2015 38 /120
Confidential
When select DHCP Mode as Server, the window will display as the following screenshot.
DHCP Server
Item
Description
Default
Enable
Click the switch to show “ON” and to enable DHCP function.
ON
Mode
Server: Lease IP address to DHCP clients which connect to LAN.
Relay: Router can be DHCP Relay, which will provide a relay tunnel to
solve problem that DHCP Client and DHCP Server is not in a same subnet.
DHCP
Server
IP Pool Start
Define the beginning of the pool of IP addresses which will lease to DHCP
clients.
192.168
.0.2
IP Pool End
Define the end of the pool of IP addresses which will lease to DHCP
clients.
192.168
.0.100
Subnet Mask
Define the Subnet Mask which the DHCP clients will obtain from DHCP
server.
255.255
.255.0
Gateway
Define the Gateway which the DHCP clients will obtain from DHCP server.
Null
Primary DNS
Define the Primary DNS Server which the DHCP clients will obtain from
DHCP server.
Null
Secondary DNS
Define the Secondary DNS Server which the DHCP clients will obtain from
DHCP server.
Null
WINS Server
Define the Windows Name Server which the DHCP clients will obtain
from DHCP server.
Null
Lease Time
Define the time which the client can use the IP address which obtained
from DHCP server.
120

Robustel GoRugged R2000 Specifications

General

Model	GoRugged R2000
Category	Network Router
Ethernet Ports	2 x 10/100 Mbps
SIM Slots	2
Power Supply	9-36 VDC
USB Port	1 x USB 2.0
Cellular Connectivity	4G LTE, 3G
VPN Support	IPsec, OpenVPN, GRE
Operating Temperature	-40°C to +75°C
WiFi	802.11 b/g/n
Serial Interface	RS232/RS485
GPS	Yes
Firewall	SPI Firewall
Digital Input/Output	2 x DI
