Robustel GoRugged R2000 User Guide
RT_UG_R2000_v.1.2.0 15.12.2015 28 /120
Confidential
3.6 Interface->Link Manager
Link Manager
User can manage the link connection in this section.
Select from “WWAN1”, “WWAN2”, “WAN”, “WLAN”.
1. WWAN1: Select to make SIM1 as the primary wireless link.
Note: insert SIM card please refer to the installation quick guide.
2. WWAN2: Select to make SIM2 as the primary wireless link.
3. WAN: Select to make WAN Ethernet port as the primary link.
Note: WAN link available only if enable ETH0 as WAN interface in
System->Device Configuration->Advance Device Settings
4. WLAN: Select to make WLAN as the router’s primary link.
Note: WLAN link available only if enable R2000 as WiFi Client in
System->Device Configuration->Advance Device Settings
Select from “None”, “WWAN1”, “WWAN2”, “WAN”, “WLAN”.
1. None: Do not select backup interface.
2. WWAN1: Select to make SIM1 as backup wireless WAN.
3. WWAN2: Select to make SIM2 as backup wireless WAN.
4. WAN: Select to make WAN Ethernet port as the backup WAN.
Note: WAN link available only if enable ETH0 as WAN interface in
System->Device Configuration->Advance Device Settings
5. WLAN: Select to make WLAN as the router’s backup link.
Note: WLAN link available only if enable R2000 as WiFi Client in
System->Device Configuration->Advance Device Settings
Cold backup: The inactive link is offline on standby.
Warm backup: The inactive link is online on standby.
Warm backup mode is not available for dual SIM backup.
Enable to reboot the whole system if no links available.
