Robustel GoRugged R2000 User Guide
RT_UG_R2000_v.1.2.0 15.12.2015 17 /120
Confidential
Note:
1. Recommended torque for inserting is 0.5N.m and the maximum torque is 0.7N.m.
2. Please use the specific M2M SIM card when the device works in extreme temperature (temperature exceeding
0-40
℃
), because the long-time working of regular SIM card in harsh environment (temperature exceeding
0-40
℃
)may increase the possibility of SIM card failure.
3. Don’t forget screw the cover for again-theft.
4. Don’t touch the metal surface of the SIM card in case information in the card is lost or destroyed.
5. Don’t bend or scratch your SIM card. Keep the card away from electricity and magnetism.
6. Make sure router is power off before inserting or removing your SIM card.
2.6 Connect the External Antenna
Connect router with an external antenna connector. Make sure the antenna is within correct frequency range and is
screwed tightly. Recommended torque for mounting is 0.35N.m
2.7 Ground the Router
Grounding and wire router helps limit the effects of noise due to electromagnetic interference (EMI). Run the ground
connection from the ground by screwing to the grounding surface before connecting devices.
Note: This product is intended to be mounted to a well-grounded mounting surface, such as a metal panel.
2.8 Mount the Router
The router may be placed on a horizontal surface such as a desktop, mounted on a DIN-rail, or mounted on the wall.
Two ways of mounting the router
1. Use 4 pcs of M2.5 screw to fix the router on the two metal plates.
And then use 2 pcs of M2.5 countersunk head cross recess screws with point-end to mount the router with two
metal plates on the wall.
Recommended torque for mounting is 0.5N.m and the maximum torque is 0.7N.m.
2. Mount the router on a DIN rail with 3 pcs of M3 countersunk head cross recess screws, and then hang the
DIN-Rail on the holder.
You need to choose a standard holder. Recommended torque for mounting is 1.0N.m and the maximum torque
is 1.2N.m.
Note: When mounting the unit on a DIN-rail, make sure that it is oriented with the metal springs on top.
