Robustel GoRugged R2000 User Manual

Robustel GoRugged R2000 User Guide
RT_UG_R2000_v.1.2.0 15.12.2015 76 /120
Confidential
3.18 Services->NTP
This section allows users to set the NTP parameters.
Timezone Settings @ NTP
Item
Description
Default
Time Zone
Select your local time zone.
UTC
+08:00
Expert Setting
Specify the time zone with Daylight Saving Time in TZ environment variable
format. The Time Zone option will be ignored in this case.
Null
NTP Client Setting @ NTP
Enable
Click to enable the router to synchronize time from NTP server.
Note: R2000 doesn’t have the RTC, so NTP client function must always be ON.
ON
Primary NTP Server
Enter primary NTP Server’s IP address or domain name.
pool.nt
p.org
Secondary NTP Server
Enter secondary NTP Server’s IP address or domain name.
Null
NTP Update interval
Enter the interval (minutes) which NTP client synchronize the time from NTP
server. Minutes wait for next update, 0 means update only once.
0
NTP Client Setting @ NTP
Enable
Click to enable the NTP server function of router.
OFF
The status part of NTP allows user to check the current time of R2000 and also synchronize the router time with PC.
Click button to make the router time synchronize with PC.

Robustel GoRugged R2000 Specifications

General

Model	GoRugged R2000
Category	Network Router
Ethernet Ports	2 x 10/100 Mbps
SIM Slots	2
Power Supply	9-36 VDC
USB Port	1 x USB 2.0
Cellular Connectivity	4G LTE, 3G
VPN Support	IPsec, OpenVPN, GRE
Operating Temperature	-40°C to +75°C
WiFi	802.11 b/g/n
Serial Interface	RS232/RS485
GPS	Yes
Firewall	SPI Firewall
Digital Input/Output	2 x DI
