Robustel GoRugged R2000 User Manual

Robustel GoRugged R2000 User Guide
RT_UG_R2000_v.1.2.0 15.12.2015 57 /120
Confidential
DMZ
DMZ
Item
Description
Default
Enable DMZ
Select to enable the DMZ function.
DMZ host is a host on the internal network that has all ports exposed,
except those ports otherwise forwarded.
OFF
Host IP Address
Enter the IP address of the DMZ host which on the internal network.
Null
Source IP Address
Set the address which can talk to the DMZ host. Null means for any
addresses.
Null
3.14 VPN->IPSec
This section allows users to set the IPSec and the related parameters.
General
General
Item
Description
Default
Enable NAT Traversal
Tick to enable NAT Traversal for IPSec. This item must be enabled when
router under NAT environment.
ON
Keepalive
The interval that router sends packets to NAT box so that to avoid it remove
the NAT mapping.
60
Debug Enable
Enable this function, and it will output IPSec information to the debug port.
OFF

Robustel GoRugged R2000 Specifications

General

Model	GoRugged R2000
Category	Network Router
Ethernet Ports	2 x 10/100 Mbps
SIM Slots	2
Power Supply	9-36 VDC
USB Port	1 x USB 2.0
Cellular Connectivity	4G LTE, 3G
VPN Support	IPsec, OpenVPN, GRE
Operating Temperature	-40°C to +75°C
WiFi	802.11 b/g/n
Serial Interface	RS232/RS485
GPS	Yes
Firewall	SPI Firewall
Digital Input/Output	2 x DI
