Robustel GoRugged R2000 User Manual

Robustel GoRugged R2000 User Guide
RT_UG_R2000_v.1.2.0 15.12.2015 72 /120
Confidential
3.16 Services->Syslog
This section allows users to set the syslog parameters.
Syslog
Syslog Settings
Item
Description
Default
Enable
Click to enable Syslog setting.
OFF
Syslog Level
Select form “Debug”, “Info”, “Notice”, “Warning”, “Error” which from low to
high. The lower level will output more syslog in detail.
Notice
Save Position
Select the save position from “RAM”, “NVM” and “Console”. Choose “RAM”,
the data will be cleared after reboot. But it's not recommended that saving
syslog to NVM (Non-Volatile Memory) for a long time.
RAM
Log to Remote
Enable to allow router sending syslog to the remote syslog server. You need to
enter the IP and Port of the syslog server.
OFF
Application Debug Control
Enable Modem Debug
Click to enable router to debug Modem.
ON
Enable Link Manager
Debug
Click to enable router to debug Link Manager.
ON
Enable APP Debug
Click to enable router’s debug control for all other applications.
ON

Robustel GoRugged R2000 Specifications

General

Model	GoRugged R2000
Category	Network Router
Ethernet Ports	2 x 10/100 Mbps
SIM Slots	2
Power Supply	9-36 VDC
USB Port	1 x USB 2.0
Cellular Connectivity	4G LTE, 3G
VPN Support	IPsec, OpenVPN, GRE
Operating Temperature	-40°C to +75°C
WiFi	802.11 b/g/n
Serial Interface	RS232/RS485
GPS	Yes
Firewall	SPI Firewall
Digital Input/Output	2 x DI
