Robustel GoRugged R2000 User Guide
RT_UG_R2000_v.1.2.0 15.12.2015 93 /120
Confidential
Enter the trace destination IP address or domain name.
Specify the max trace hops. Router will stop tracing if the trace hops has met
max value no matter the destination has been reached or not.
Specify timeout of Traceroute request.
Click this button to start Traceroute request, and the log will be displayed in
the follow box.
Click this button to stop Traceroute request
Select form “All”, “ETH1”, and “ETH2”:
All: contain all the interface;
ETH1: Ethernet interface1;
ETH2: Cellular WAN.
Filter the packet that contain the specify IP address.
Set the packet number that the router can sniffer at a time.
Select from “All”, “IP”, “TCP”, “UDP” and “ARP”.
Set the port number for TCP or UDP that is used in sniffer.
Show the current status of sniffer.
Click this button to start the sniffer.
Click this button to stop the sniffer. Once click the stop button, a new log file
will be displayed in the follow List.
Every times of sniffer log will be saved automatically as a new file. You can find
the file from this Sniffer Traffic Data List and click to download the log,
click to delete the log file. It can cache a maximum of 5 files.
