Robustel R2000 User Manual

Robustel R2000 User Guide
RT_UG_R2000_v.3.0.0 July 24, 2017 13 / 124
Confidential
 VPN tunnel: IPsec, OpenVPN, GRE
 Firewall: DMZ, anti-DoS, Filtering (IP/Domain name/MAC address), Port Mapping, Access Control
 Management: Web, CLI, SMS
 Serial port: Transparent, TCP Client/Server, UDP, Modbus RTU Gateway
App Center (Available Apps for RobustOS)
 Apps: L2TP, PPTP, DMVPN, RobustVPN, DDNS, VRRP, QoS, Captive Protal, WLAN Multi AP, SNMP, Language,
RobustLink
*Request on demand. For more Apps please visit www.robustel.com.
Power Supply and Consumption
 Connector: 3-pin 3.5 mm female socket
 Input voltage: 9 to 26V DC (A014401/A014402/A014403/A014404/A014405/A014406/A014701/A014702/
A014703/A014704/A014705/A014706) or 9 to 36V DC
 Power consumption: Idle: 100 mA@12 V
Data link: 500 mA (peak) @12 V
 PD feature (optional): WAN port supported
Input voltage: 48~57V DC
*It is not recommended to use DC power supply and PD power supply simultaneously.
Physical Characteristics
 Ingress protection: IP30
 Housing & Weight: Metal, 305 g
 Dimensions: 127.5 x 82.5 x 29.5 mm
 Installations: Desktop, wall mounting or 35 mm DIN rail mounting
Certifications
 Approvals & Certificates: CE, RCM
 EMC:
EMI: EN 55022: 2006/A1: 2007 (CE & RE) Class B
EMS: IEC 61000-4-2 (ESD) Level 4
IEC 61000-4-4 (EFT) Level 3
IEC 61000-4-5 (Surge) Level 3

Robustel R2000 Specifications

General

Model	R2000
Category	Network Router
Cellular Connectivity	4G LTE
WAN Ports	1
Ethernet Ports	2
Input Voltage	9-36 VDC
SIM Slots	2
Certifications	CE, FCC, RoHS
Operating Temperature	-40°C to 75°C
