Robustel R2000 User Manual

Robustel R2000 User Guide
RT_UG_R2000_v.3.0.0 July 24, 2017 45 / 124
Confidential
3.8 Interface > Ethernet
This section allows you to set the related parameters for Ethernet. There are two Ethernet ports on R2000 Router,
including ETH0 and ETH1. The ETH0 on the router can be configured as either a WAN port or LAN port, while ETH1
can only be configured as a LAN port. The ETH0 and ETH1 can freely choose from lan0 and lan1, but at least one LAN
port must be assigned as lan0. The default settings of ETH0 and ETH1 are lan0 and their default IP are
192.168.0.1/255.255.255.0.
Click button of eth0 to configure its parameters.
Port Settings
Item
Description
Default
Index
Indicate the ordinal of the list.
--
Port
Show the editing port, read only.
--
Port Assignment
Choose the Ethernet port’s type, as a WAN port or LAN port. When setting the port
as a LAN port in Interface > LAN > LAN > Network Settings > General Settings, you
can click the drop-down list to select from “lan0” or “lan1”.
lan0
This column allows you to view the status of Ethernet port.

Robustel R2000 Specifications

General

Model	R2000
Category	Network Router
Cellular Connectivity	4G LTE
WAN Ports	1
Ethernet Ports	2
Input Voltage	9-36 VDC
SIM Slots	2
Certifications	CE, FCC, RoHS
Operating Temperature	-40°C to 75°C
