Robustel R2000 User Manual

Robustel R2000 User Guide
RT_UG_R2000_v.3.0.0 July 24, 2017 12 / 124
Confidential
1.3 Specifications
Cellular Interface
 Number of antennas: 2 (MAIN + AUX)
 Connector: SMA, female
 SIM: 2 (3.0 V & 1.8 V)
 Standards: GSM/GPRS/EDGE/WCDMA/HSDPA/HSUPA/HSPA+/DC-HSPA+/TD-SCDMA/CDMA (CDMA
1X/EVDO)/FDD LTE/TDD LTE
GSM: max DL/UL = 9.6/2.7 Kbps
GPRS: max DL/UL = 86 Kbps
EDGE: max DL/UL = 236.8 Kbps
WCDMA/TD-SCDMA: max DL/UL = 2.8 Mbps/384 Kbps
EVDO: max DL/UL = 5.4 Mbps/14.7 Kbps
HSPA+: max DL/UL = 21/5.76 Mbps, fallback to 2G
DC-HSPA+: max DL/UL = 42/5.76 Mbps, fallback to 2G
FDD LTE: max DL/UL = 100/50 Mbps, fallback to 2G/3G
TDD LTE: max DL/UL = 100/50 Mbps, fallback to 2G/3G
Ethernet Interface
 Number of ports: 2 x 10/100 ports, 2 x LAN or 1 x LAN + 1 x WAN
 WAN port: Supporting 802.3 at PD feature (optional)
 Magnet isolation protection: 1.5 KV
WiFi Interface (Optional)
 Number of antennas: 2 (WiFi1 + WiFi2)
 Connector: RP-SMA, male
 Standards: 802.11b/g/n, supporting AP and Client modes
 Frequency bands: 2.412 - 2.484 GHz (2.4 GHz ISM band)
 Security: WEP, WPA, WPA2
 Encryption: 68/124 AES, TKIP
 Data speed: 2*2 MIMO, 300 Mbps
 Receiving sensitivity: 802.11b -93 dBm
(+/- 1 dBm) 802.11g -90 dBm
802.11n (20 MHz) -88 dBm
802.11n (40 MHz) -85 dBm
Others
 Reset button : 1 x RST
 LED indicators: 1 x RUN, 1 x PPP, 1 x USR, 3 x RSSI
 Built-in: Watchdog, Timer
Software (Basic features of RobustOS)
 Network protocols: PPP, PPPoE, TCP, UDP, DHCP, ICMP, NAT, HTTP, HTTPs, DNS, ARP, RIP, OSPF, NTP, SMTP, Telnet,
VLAN, SSH2, etc.

Robustel R2000 Specifications

General

Model	R2000
Category	Network Router
Cellular Connectivity	4G LTE
WAN Ports	1
Ethernet Ports	2
Input Voltage	9-36 VDC
SIM Slots	2
Certifications	CE, FCC, RoHS
Operating Temperature	-40°C to 75°C
