Robustel R2000 User Manual

Robustel R2000 User Guide
RT_UG_R2000_v.3.0.0 July 24, 2017 30 / 124
Confidential
Link Settings allows you to configure the parameters of link connection, including WWAN1/WWAN2, WAN and
WLAN.
It is recommended to enable Ping detection to keep the router always online. The Ping detection increases the
reliability and also costs the data traffic.
Click on the right-most of WWAN1/WWAN2 to enter the configuration window.
WWAN1/WWAN2
The window is displayed as below when enabling the “Automatic APN Selection” option.

Robustel R2000 Specifications

General

Model	R2000
Category	Network Router
Cellular Connectivity	4G LTE
WAN Ports	1
Ethernet Ports	2
Input Voltage	9-36 VDC
SIM Slots	2
Certifications	CE, FCC, RoHS
Operating Temperature	-40°C to 75°C
