Robustel R2000 User Guide
RT_UG_R2000_v.3.0.0 July 24, 2017 63 / 124
Confidential
Click to add port mapping rules. The maximum rule count is 40.
Indicate the ordinal of the list.
Enter a description for this port mapping.
Specify the host or network which can access the local IP address. Empty
means unlimited, e.g. 10.10.10.10/255.255.255.255 or 192.168.1.0/24
Enter the internet port of router which can be accessed by other hosts
from internet.
Enter router’s LAN IP which will forward to the internet port of router.
Enter the port of router’s LAN IP.
Select from “TCP”, “UDP” or “TCP-UDP” as your application required.
Click the toggle button to enable/disable DMZ. DMZ host is a host on the
internal network that has all ports exposed, except those ports otherwise
forwarded.
Enter the IP address of the DMZ host on your internal network.
Set the address which can talk to the DMZ host. 0.0.0.0 means for any
addresses.
