Rockwell Automation Allen-Bradley Guardmaster CIP User Manual

16 Rockwell Automation Publication 843ES-UM001A-EN-P - February 2020
Chapter 1 Product Overview
Table 6 - Cordset — M12 Flex-rated
First End Connector Second End Connector Cable Type Cat. No.
(1)
(1) The 2 at the end of the cat. no. is for 2 m (6.6 ft) cable length. Replace the 2 with 1 (1 m [3.3 ft]), 5 (5 m [16.4 ft]) or 10 (10 m
[32.8 ft]) for standard cable lengths.
Male M12 D-Code, straight Flying leads
Foil and braided shield, 4
conductor, teal PUR, flex
rated, halogen-free
1585D-M4UB-2
Table 7 - Patchcord — M12 Flex-rated
First End Connector Second End Connector Cable Type Cat. No.
(1)
(1) The 2 at the end of the cat. no. is for 2 m (6.6 ft) cable length. Replace the 2 with 1 (1 m [3.3 ft]), 5 (5 m [16.4 ft]) or 10 (10 m
[32.8 ft]) for standard cable lengths.
Male M12 D-Code, Straight Male M12 D-Code, Straight
Foil and braided
shield, 4 conductor,
teal PUR, flex rated,
halogen-free
1585D-M4UBDM-2
Male M12 D-Code, Right Angle Male M12 D-Code, Right Angle 1585D-E4UBDE-2
Male M12 D-Code, Straight Male M12 D-Code, Right Angle 1585D-M4UBDE-2
Male M12 D-Code, Straight Female M12 D-Code, Straight
1585D-M4UBDF-2
Table 8 - Patchcord — M12 to RJ45 Flex-rated
First End Connector Second End Connector Cable Type Cat. No.
(1)
(1) The 2 at the end of the cat. no. is for 2 m (6.6 ft) cable length. Replace the 2 with 1 (1 m [3.3 ft]), 5 (5 m [16.4 ft]) or 10 (10 m
[32.8 ft]) for standard cable lengths.
Male M12 D-Code RJ45
Foil and braided shield, 4
conductor, teal PUR, flex
rated, halogen-free
1585D-M4UBJM-2
