54 Rockwell Automation Publication 843ES-UM001A-EN-P - February 2020
Chapter 5 Configure the Encoder with Studio 5000 Environment
Edit the Module
Configuration Common
Categories
You click the category names in the New Module dialog box to view and change
the configuration parameters.
The following common categories are described in this section:
• General
•Connection
•Safety
•Module Info
General
The General page appears first when you create a module. The parameters in this
category are the same for all 843ES CIP Safety encoder modules. You use this
category to complete the following tasks:
• Name the module
• Describe the module
• Access the module definition
Safety Network Number
The purpose of the safety network number (SNN) is to make sure that every
module in a system can be uniquely identified. During configuration, the Logix
Designer application defaults an SNN of a safety device to match the SNN of the
first safety node on each network. In most cases, you can use the default SNN.
IMPORTANT This chapter shows how to edit configuration when you add the module to the
Logix Designer application project. If you access the module configuration after
it is added to the project, the dialog box is named Module Properties. The same
categories are displayed as the categories displayed on the New Module dialog
box.
