Rockwell Automation Publication 843ES-UM001A-EN-P - February 2020 79
Appendix A
Specifications
General
Safety
Table 29 - Electromagnetic Compatibility (EMC)
Attribute All Cat. Nos.
Relevant standards EN 55011 Class B
IEC 61326-1
IEC 61326-3-1
ESD immunity IEC 61000-4-2; 9 kV contact discharges; 10 kV air discharges
Radiated EMF immunity IEC 61000-4-3: 80…1000 MHz, 10V/m 80% AM 1 kHz; 1.4…2.0 GHz 3V/m 80% AM 1 kHz
IEC 61000-4-3: 80…1000 MHz, 20V/m 80% AM 1 kHz; 1.4…2.0 GHz 10v/m 80% AM 1 kHz;
2.0…2.7 GHz 3V/m 80% AM 1 kHz
Surge transient immunity IEC 61000-4-5: ±2 kV line-earth (CM) on Ethernet ports
EFT/B immunity IEC 61000-4-4: ±2 kV at 5 kHz on Ethernet ports
Conducted RF immunity IEC 61000-4-6: 0.15…80 MHz, 3V/m 80% AM 1 kHz
Magnetic influence, max IEC 61000-4-8, 100 A/m
Protection Short circuit, overload, reverse polarity, over voltage, loss of ground
Table 30 - Network
Attribute All Cat. Nos.
EtherNet/IP IEC 61784-1
IP IPv4
Ethernet connector 2 Ethernet M12, 4-pin, female, D-coded
EtherNet/IP communication
rate
10/100 Mbps
Prioritization Via. 802.1 Q/D
Coarse update rate, max 1 ms
Safe coarse update rate, max 6 ms
Broadcast rate limiting 1%
Jitter 100 ns
Duplex Full or half
Attribute All Cat. Nos.
Category Cat. 3, HFT = 1
System structure 2 channels (Cat. 3)
Standards
Safety Classification
Safety functions according to IEC 61800-5-2
PLe according to ISO 13849-1, ISO 13849-2
SIL 3 per IEC 62061, IEC 61508, and IEC 61800-5-2
Functional safety data PFH
d
= 8.03E-9 (average frequency of a dangerous failure per hour)
Certifications CE Marked for all applicable directives, c-UL-us (UL 61010), and TÜV, see rok.auto/certifications
Mission time 20 years
Diagnostic coverage (DC) ≥99%
Error presumptions IEC 61800-5-2
CIP Safety ODVA CIP Volume 5
