Rockwell Automation Publication 843ES-UM001A-EN-P - February 2020 33
Installation Chapter 3
Figure 5 - Solid Shaft with Synchro Flange [mm (in.)]
Figure 6 - Solid Shaft with Square Flange [mm (in.)]
()
71.5 (2.81)
3 (0.12)
4 (0.16)
61 (2.4)
3 (0.12)
ØD f7
Ø59
(2.32)
Ø58
(2.28)
3 x 120°
17°
Ø42 (1.65)
20 (0.79)
3 (0.12 )
N9
Ø50
(1.97)
N9
22.225 (0.875) - 3/8 in. shaft
7.5 (0.3)
7.1 (0.28)
75.5 (2.97)
57.5 (2.26)
68 (2.68)
ØD f7
Ø59
(2.32)
52.4
(2.06)
63.5
(2.5)
20 (0.79)
Ø36
(1.42)
3
(0.12 )
N9
N9
22.225 (0.875) - 3/8 in. shaft
