Rockwell Automation Publication 2080-UM002L-EN-E - November 2021 135
Chapter 8 Use the High-Speed Counter and Programmable Limit Switch
This bit is maintained by the controller and is set when there is an HSC error.
This bit can be cleared by the user, if necessary.
The Count Up bit is used with all of the HSCs (modes 0…9). If the
HSCSTS.CountEnable bit is set, the Count Up bit is set (1). If the
HSCSTS.CountEnable is cleared, the Count Up bit is cleared (0).
The Count Down bit is used with the bidirectional counters (modes 2…9). If the
HSCSTS.CountEnable bit is set, the Count Down bit is set (1). If the
HSCSTS.CountEnable bit is clear, the Count Down bit is cleared (0).
The Mode Done status flag is set (1) by the HSC sub-system when the HSC is
configured for Mode 0 or Mode 1 behavior, and the accumulator counts up to
the High Preset.
The HSCSTS.OVF status flag is set (1) by the HSC sub-system whenever the
accumulated value (HSCSTS.Accumulator) has counted through the overflow
variable (HSCAPP.OFSetting).
This bit is transitional and is set by the HSC sub-system. It is up to the control
program to utilize, track if necessary, and clear (0) the overflow condition.
Overflow conditions do not generate a controller fault.
The Underflow status flag is set (1) by the HSC sub-system whenever the
accumulated value (HSCSTS.Accumulator) has counted through the underflow
variable (HSCAPP.UFSetting).
Count Up (HSCSTS.CountUpFlag)
Description Data Format
HSC Modes
(1)
(1) For Mode descriptions, see HSC Mode (HSCAPP.HSCMode) on page 127.
User Program Access
HSCSTS.CountUpFlag bit 0…9 read only
Count Down (HSCSTS.CountDownFlag)
Description Data Format
HSC Modes
(1)
(1) For Mode descriptions, see HSC Mode (HSCAPP.HSCMode) on page 127.
User Program Access
SCSTS.CountDownFlag bit 2…9 read only
Mode Done (HSCSTS.Mode1Done)
Description Data Format
HSC Modes
(1)
(1) For Mode descriptions, see HSC Mode (HSCAPP.HSCMode) on page 127.
User Program Access
HSCSTS.Mode1Done bit 0 or 1 read/write
Overflow (HSCSTS.OVF)
Description Data Format
HSC Modes
(1)
(1) For Mode descriptions, see HSC Mode (HSCAPP.HSCMode) on page 127.
User Program Access
HSCSTS.OVF bit 0…9 read/write
Underflow (HSCSTS.UNF)
Description Data Format
HSC Modes
(1)
(1) For Mode descriptions, see HSC Mode (HSCAPP.HSCMode) on page 127.
User Program Access
HSCSTS.UNF bit 0…9 read/write
