Rockwell Automation Allen-Bradley PowerFlex 700S Programming Manual

102 Rockwell Automation Publication 20D-PM001D-EN-P - March 2019
Chapter 2 Programming and Parameters
712 Write Mask Act
Status of write access for DPI ports. When bit 15 “Security” is set, network security controls the write mask instead of Par 669 [Write Mask].
Note: This parameter was added for firmware version 3.001.
713 Logic Mask Act
Indicates status of the logic mask for DPI ports. When bit 15 “Security” is set, network security controls the logic mask instead of Par 670 [Logic Mask].
Note: This parameter was added for firmware version 3.001.
714 Port Mask Act
Bits 0-5 indicate status for DPI port communication. Bit 15 “Security” indicates when security software controls the parameter.
Note: This parameter was added for firmware version 3.001.
717 PLL TP Select
Phase Locked Loop test point selection.
Note: This parameter was added for firmware version 3.001.
Default:
Options:
0 =
0 =
1 =
2 =
3 =
4 =
5 =
6 =
7 =
8 =
9 =
10 =
11 =
12 =
13 =
14 =
“Zero”
“Zero” 15 = “Vel Lpf In”
“Bg Once” 16 = “Vel Lpf Out”
“Position Err” 17 = “k1”
“X to V” 18 = “k2”
“Dt” 19 = ”k3”
“Gain” 20 = “pi”
“Pos Intg” 21 = “Ve Enable”
“Cal” 22 = “Ve In”
“Epr Cal” 23 = “Ve Out”
“Num” 24 = “Ve AnaPlsScl”
“Denom” 25 = “Ve Whl Accum”
“Egr Ratio” 26 = “Ve Frc AccmF”
“A Comp” 27 = “Ve Frc AccmI”
“H Comp” 28 = “Ve Dt”
“Pos Lpf Out”
718 PLL TP DataDInt
Test point integer data. This data is meaningful only if the selection at Par 717 [PLL TP Select] is integer data.
Note: This parameter was added for firmware version 3.001.
Default:
Min/Max:
0
-/+2147483648
RO 32-bit
Integer
719 PLL TP DataReal
Test point real data. This data is meaningful only if the selection at Par 717 [PLL TP Select] is not integer data.
Note: This parameter was added for firmware version 3.001.
Default:
Min/Max:
0.0
-/+2200000000.0000
RO Real
720 PLL Control
Phase Locked Loop Control.
Bit 0 “Vel FdFwd En” - When set, enables the velocity feed forward path. When cleared, the feed forward path is disabled.
Bit 1 “Ext Vel In” - When set, enables external velocity feed forward through Par
728 [PLL Ext Spd Ref]. When cleared, velocity feed forward is derived from the input device position.
Bit 2 “Trckng AComp” - When set, provides an element of acceleration compensation to the feed forward branch. This is not recommended for use with external inputs because of increased noise.
Note: This parameter was added for firmware version 3.001.
No. Name
Description
Values
Linkable Read-Write Data Type
Options
Security Reserved Reserved Reserved Reserved Reserved Reserved Reserved DriveLogix Reserved Int DPI Comm Reserved Aux DPI Conn Ext DPI Conn Local HIM Terminal Blk
Default 0xxxxxxx0x0x0000
Bit 1514131211109876543210
0 = False
1 = True
Options
Security Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved DPI Port 5 Reserved DPI Port 3 DPI Port 2 DPI Port 1 Digital In
Default 0xxxxxxxxx0x0000
Bit 1514131211109876543210
0 = False
1 = True
Options
Security Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved DPI Port 5 Reserved DPI Port 3 DPI Port 2 DPI Port 1 Digital In
Default 0xxxxxxxxx0x0000
Bit 1514131211109876543210
0 = False
1 = True
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Trckng HComp Trckng AComp Ext Vel In Vel FdFwd En
Default xxxxxxxxxxxx0000
Bit 1514131211109876543210
0 = False
1 = True
