98 Rockwell Automation Publication 20D-PM001D-EN-P - March 2019
Chapter 2 Programming and Parameters
No. Name
Description
Values
Linkable Read-Write Data Type
626
to
646
To DriveLogix00
to
To DriveLogix20
These parameters display the output values communicated from the PowerFlex 700S drive to the DriveLogix
controller.
Default:
Min/Max:
0
-/+32 (dependant on Par
625 [To DL DataType])
Y
RO Set by Par
625
650 DPI In DataType
Sets the data type for each word communicated from an external controller to the PowerFlex 700S drive via a DPI communication module. Setting a bit high will configure the associated word as a
Real data type and setting the bit low will configure it for Integer data type.
651
652
653
654
655
656
657
658
DPI Data In A1
DPI Data In A2
DPI Data In B1
DPI Data In B2
DPI Data In C1
DPI Data In C2
DPI Data In D1
DPI Data In D2
These parameters display the input values communicated from DPI communication modules to the PowerFlex
700S drive.
Default:
Min/Max:
0
-/+32 (dependant on Par
650 [DPI In
DataType])
RO 32-bit
Integer
659 DPI Out DataType
Sets the data type for each word communicated from the PowerFlex 700S drive to an external controller via a DPI communication module. Setting a bit high will configure the associated word as a
Real data type and setting the bit low will configure it for Integer data type.
660
661
662
663
664
665
666
667
DPI Data Out A1
DPI Data Out A2
DPI Data Out B1
DPI Data Out B2
DPI Data Out C1
DPI Data Out C2
DPI Data Out D1
DPI Data Out D2
These parameters display the output values communicated from the PowerFlex 700S drive to DPI communication
modules.
Default:
Min/Max:
0
-/+32 (dependant on Par
659 [DPI Out
DataType])
Y
RW Set by Par
659
669 Write Mask
Enables/disables write access (parameters, links, etc.) for DPI ports. Changes to this parameter only become effective when power is cycled, the drive is reset or bit 15 “Security” of Par 712 [Write
Mask Act], transitions from “1” to “0.”
Note: This parameter was added for firmware version 3.001.
Options
DPI D2 Real DPI D1 Real DPI C2 Real DPI C1 Real DPI B2 Real DPI B1 Real DPI A2 Real DPI A1 Real
Default 00000000
Bit 76543210
0 = False
1 = True
Options
DPI D2 Real DPI D1 Real DPI C2 Real DPI C1 Real DPI B2 Real DPI B1 Real DPI A2 Real DPI A1 Real
Default 00000000
Bit 76543210
0 = False
1 = True
Options
DriveLogix Reserved Int DPI Comm Reserved Aux DPI Conn Ext DPI Conn Local HIM Terminal Blk
Default 111x1111
Bit 76543210
0 = False
1 = True
