Rockwell Automation Allen-Bradley PowerFlex 700S Programming Manual

Rockwell Automation Publication 20D-PM001D-EN-P - March 2019 119
Programming and Parameters Chapter 2
927 SL Mult State
Displays the status of the SynchLink Multiply function.
• Bit 0 “Local Ovflow” indicates a math overflow due to local multiply.
• Bit 1 “Rx Ovflow” indicates a math overflow in received data.
• Bit 3 “Ftol Ovflow” indicates a math overflow in the real to integer conversion function.
928 Rx Dir Data Type
Sets the data type for the SynchLink received direct words. If the word's bit is set the data type is floating point (real). If the bit is not set the data type is integer.
929
to
932
SL Dir Data Rx00
to
SL Dir Data Rx03
This is the SynchLink direct data received. See Par 928 [Rx Dir Data Type] for data type configuration.
Default:
Min/Max:
0
32 bits of data
RO 32-bit
Integer
933 Rx Buf Data Type
Sets the data type for the SynchLink received buffered data. If the word's bit is set the data type is floating point (real). If the bit is not set the data type is integer.
934
to
951
SL Buf Data Rx00
to
SL Buf Data Rx17
This is the SynchLink buffered data received. See Par 933 [Rx Buf Data Type] for data type configuration.
Default:
Min/Max:
0
32 bits of data
RO 32-bit
Integer
964 Tx Dir Data Type
Indicates the data type of each Direct Transmit word. If the word's bit is set the data type is floating point (real). If the bit is not set the data type is integer. Use the Peer Communication window to
configure this selection.
965
to
968
SL Dir Data Tx00
to
SL Dir Data Tx03
This is the SynchLink direct data transmitted. See Par 964 [Tx Dir Data Type] for data type configuration.
Default:
Min/Max:
0
32 bits of data
Y
RW 32-bit
Integer
969 Tx Buf Data Type
Indicates the data type of each Buffered Transmit word. If the word's bit is set the data type is floating point (real). If the bit is not set the data type is integer. Use the Peer Communication window
to configure this selection.
970
to
987
SL Buf Data Tx00
to
SL Buf Data Tx17
This is the SynchLink buffered data transmitted. See Par 969 [Tx Buf Data Type] for data type configuration.
Default:
Min/Max:
0
32 bits of data
Y
RO
W
32-bit
Integer
No. Name
Description
Values
Linkable Read-Write Data Type
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved FtoI Ovflow Reserved Rx Ovflow Local Ovflow
Default xxxxxxxxxxxxxxxxxxxxxxxxxxxx0x00
Bit 313029282726252423222120191817161514131211109876543210
0 = False
1 = True
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved SLDir03 Real SLDir02 Real SLDir01 Real SLDir00 Real
Default xxxxxxxxxxxxxxxxxxxxxxxxxxxx0000
Bit 313029282726252423222120191817161514131211109876543210
0 = False
1 = True
Options
Reserved Reserved SLBuf29 Real SLBuf28 Real SLBuf27 Real SLBuf26 Real SLBuf25 Real SLBuf24 Real SLBuf23 Real SLBuf22 Real SLBuf21 Real SLBuf20 Real SLBuf19 Real SLBuf18 Real SLBuf17 Real SLBuf16 Real SLBuf15 Real SLBuf14 Real SLBuf13 Real SLBuf12 Real SLBuf11 Real SLBuf10 Real SLBuf09 Real SLBuf08 Real SLBuf07 Real SLBuf06 Real SLBuf05 Real SLBuf04 Real SLBuf03 Real SLBuf02 Real SLBuf01 Real SLBuf00 Real
Default xx000000000000000000000000000000
Bit 313029282726252423222120191817161514131211109876543210
0 = False
1 = True
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved SLDir03 Real SLDir02 Real SLDir01 Real SLDir00 Real
Default xxxxxxxxxxxxxxxxxxxxxxxxxxxx0000
Bit 313029282726252423222120191817161514131211109876543210
0 = False
1 = True
Options
Reserved Reserved SLBuf29 Real SLBuf28 Real SLBuf27 Real SLBuf26 Real SLBuf25 Real SLBuf24 Real SLBuf23 Real SLBuf22 Real SLBuf21 Real SLBuf20 Real SLBuf19 Real SLBuf18 Real SLBuf17 Real SLBuf16 Real SLBuf15 Real SLBuf14 Real SLBuf13 Real SLBuf12 Real SLBuf11 Real SLBuf10 Real SLBuf09 Real SLBuf08 Real SLBuf07 Real SLBuf06 Real SLBuf05 Real SLBuf04 Real SLBuf03 Real SLBuf02 Real SLBuf01 Real SLBuf00 Real
Default xx000000000000000000000000000000
Bit 313029282726252423222120191817161514131211109876543210
0 = False
1 = True
