Rockwell Automation Publication 20D-PM001D-EN-P - March 2019 125
Programming and Parameters Chapter 2
1110 DelayTimer1PrSet
The time that the value in Par 1111 [DelayTimer1Accum] must reach before bit 2 “Timer Done” in Par 1112
[DelayTimer1Stats] is set.
Note: This parameter was added for firmware version 3.001.
Units:
Default:
Min/Max:
s
0
0/600.00
Y
RW 16-bit
Integer
1111 DelayTimer1Accum
The amount of time that has elapsed since the timer was enabled (Par 1112 [DelayTimer1Stats], bit 2 set).
Note: This parameter was added for firmware version 3.001.
Default:
Min/Max:
Units:
0
0/600.00
s
RO 16-bit
Integer
1112 DelayTimer1Stats
Displays the status of the user-defined on or off delay timer.
Bit 0 “Timer Enable” when this bit is set, the timer is enabled.
Bit 1 “Timer Timing” when this bit is set, the timer is running.
Bit 2 “Timer Done” when this bit is set, the timer is done.
Note: This parameter was added for firmware version 3.001.
1113 DelTmr2 TrigData
Link a word to this parameter that will control a user-defined on or off delay timer. The bit within the selected
word that will control the delay timer is set by Par 1114 [DelTmr2 Trig Bit]. The user-defined on/off delay timer is
enabled by setting bit 6 “Delay Timer” of Par
1000 [UserFunct Enable].
Note: This parameter was added for firmware version 3.001.
Default:
Min/Max:
0
32 bits of data
Y
RW 32-bit
Boolean
1114 DelTmr2 Trig Bit
Selects the bit, from the word linked to Par 1113 [DelTmr2 TrigData], that will change the status of the user-
defined delay timer to on or off. When Par 1114 [DelTmr2 Trig Bit] is a positive number, the delay timer is an “on”
timer. When Par 1114 is a negative number, the delay timer is an “off” timer.
Note: This parameter was added for firmware version 3.001.
Default:
Min/Max:
0
-/+32
Y
RW 16-bit
Integer
1115 DelayTimer2PrSet
The time that the value in Par 1116 [DelayTimer2Accum] must reach before bit 2 “Timer Done” in Par 1117
[DelayTimer2Stats] is set.
Note: This parameter was added for firmware version 3.001.
Default:
Min/Max:
Units:
0
0/60000
s
Y
RW 16-bit
Integer
1116 DelayTimer2Accum
The amount of time that has elapsed since the timer was enabled (Par 1117 [DelayTimer2Stats], bit 1 set).
Note: This parameter was added for firmware version 3.001.
Default:
Min/Max:
Units:
0
0/60000
s
RO 16-bit
Integer
1117 DelayTimer2Stats
Displays the status of the user-defined on or off delay timer.
Bit 0 “Timer Enable” when this bit is set, the timer is enabled.
Bit 1 “Timer Timing” when this bit is set, the timer is running.
Bit 2 “Timer Done” when this bit is set, the timer is done.
Note: This parameter was added for firmware version 3.001.
1120 Home Accel Time
Acceleration rate when Homing.
Note: This parameter was added for firmware version 3.001.
Default:
Min/Max:
Units:
10.00
0.01/6553.50
s
Y
RW Real
1121 Home Decel Time
Deceleration rate when Homing.
Note: This parameter was added for firmware version 3.001.
Default:
Min/Max:
Units:
10.00
0.01/6553.50
s
Y
RW Real
1122 Home Speed
Speed reference used when Homing.
Notes: This parameter was added for firmware version 3.001. The default value was changed from “0.000” to
“0.005” for firmware version 4.001.
Default:
Min/Max:
Units:
0.005
-/+ 8.000
rpm
Y
RW Real
No. Name
Description
Values
Linkable Read-Write Data Type
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Timer Done Timer Timing Timer Enable
Default xxxxxxxxxxxxx000
Bit 1514131211109876543210
0 = False
1 = True
Delay
Timer 2
1113
1117 00
DelayTimer 2 Data
1115
DelayTimer 2PrSet
1116
DelayTimer 2Stats
DelayTimer 2Accum
1114DelayTimer 2 Bit
00
00 Enabled
Timing
Done
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Timer Done Timer Timing Timer Enable
Default xxxxxxxxxxxxx000
Bit 1514131211109876543210
0 = False
1 = True
A
A
A
