54 Rockwell Automation Publication 20D-PM001D-EN-P - March 2019
Chapter 2 Programming and Parameters
254 Opt0/1 RegisCnfg
Configures the registration latch for port 0 of the feedback option card.
Bits 3 “O0 RLTrgEdg0”, 4 “O0 RLTrgEdg1”, 19 “O1 RLTrgEdg0” and 20 “O1 RLTrgEdg1” select which trigger edges signal the position (see Table 254A: Edge Selection Settings
).
Bits 5 “O0 RL DirRev, 6 “O0 RL DirFwd”, 21 “O1 RL DirRev” and 22 “O1 RL DirFwd” set the direction of position capture (see Table 254B: Direction Settings
).
Bits 8-11 configure a digital filter for the registration trigger signal. This filter can be used to reject spurious noise. The filter works by waiting a programmed time before deciding that the signal
is valid. This waiting imposes a mandatory delay in the registration signal. The filter delay is programmable in increments of 100 nanoseconds from 0 (or no delay) up to 700 nanoseconds.
255 Opt0/1 RegisCtrl
Configures the registration control on port 0 of the feedback option card.
Set bits 0 “O0 Arm Req” and 16 “01 Arm Req” to arm the registration logic for the next trigger event. The particular latch will be armed and ready to be strobed on the next occurrence of the
trigger input.
Set bits 1 “O0 DisarmReq” and 17 “01 DisarmReq” to disarm the registration logic for next trigger event.
After the registration is captured, bit 0 “O0 Arm Req” and bit 16 “O1 Arm Req” automatically resets back to 0 after found. Bit 1 “O0 DisarmReq” and bit 17 “O1 DisarmReq” are only needed to disarm
a registration latch that has not been found yet. Setting bits 1 and 17 will clear the bits 0 and 6. Setting bits 0 and 6 sets bits 0 “Opt0 Armed” and bit 16 “Opt1 Armed” and clears bits 1 “Opt0 Found”
and bit 17 “Opt1 Found” of parameter 256 [Opt0/1 RegisStat].
256 Opt0/1 RegisStat
Indicates the registration control status on port 0 of the feedback option card.
Bit 0 “Opt0 Armed” indicates the registration latch is armed.
Bit 1 “Opt0 Found” indicates the registration event has triggered the latch.
Rising edge of 'Arm request' will set the 'Armed' status bit.
Rising edge of 'Disarm request' will clear the 'Armed' status bit.
257 Opt 0 Regis Ltch
Displays the registration data of the feedback option card port 0. The registration data is the position reference
counter value latched by the external strobes. The strobe signal used to trigger the latch is configurable by the Par
254 [Opt0/1 RegisCnfg].
Default:
Min/Max:
0
-/+2147483648
RO 32-bit
Integer
258 Opt 1 Regis Ltch
Displays the registration data of the feedback option card port 0. The registration data is the position reference
counter value latched by the external strobes. The strobe signal used to trigger the latch is configurable by Par
254 [Opt0/1 RegisCnfg].
Default:
Min/Max:
0
-/+2147483648
RO 32-bit
Integer
No. Name
Description
Values
Linkable
Read-Write
Data Type
Bits 3 & 4, 19 & 20, please refer to Table 254A: Edge Selection Settings below:
Bits 5 & 6, 21 & 22, please refer to Table 254B: Direction Settings
.
Options
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
O1 RL DirFwd
O1 RL DirRev
O1 RLTrgEdg1
O1 RLTrgEdg0
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
RL Filt bit3
RL Filt bit2
RL Filt bit1
RL Filt bit0
Reserved
O0 RL DirFwd
O0 RL DirRev
O0 RLTrgEdg1
O0 RLTrgEdg0
Reserved
Reserved
Reserved
Default xxxxxxxxx0000xxxxxxx1000x1100xxx
Bit 313029282726252423222120191817161514131211109876543210
0 = False
1 = True
Table 254A: Edge Selection Settings
Bit 4/20 3/19
0 0 Capture on rising edge
0 1 Capture on falling edge
1 0 Capture on both edges
1 1 Disable capture
Table 254B: Direction Settings
Bit 6/22 5/21
0 0 Disable capture
0 1 Capture position during Reverse rotation
1 0 Capture position during Forward rotation
1 1 Capture position during either rotation
Options
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
O1 DisarmReq
O1 Arm Req
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
O0 DisarmReq
O0 Arm Req
Default xxxxxxxxxxxxxx00xxxxxxxxxxxxxx00
Bit 313029282726252423222120191817161514131211109876543210
0 = False
1 = True
Options
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Opt1 Found
Opt1 Armed
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Opt0 Found
Opt0 Armed
Default xxxxxxxxxxxxxx00xxxxxxxxxxxxxx00
Bit 313029282726252423222120191817161514131211109876543210
0 = False
1 = True
