Rockwell Automation Allen-Bradley PowerFlex 700S Programming Manual

Rockwell Automation Publication 20D-PM001D-EN-P - March 2019 55
Programming and Parameters Chapter 2
259 Stegmann0 Cnfg
Configures the Stegmann Hi-Resolution Encoder Feedback Option.
• Bit 5 “Direction” determines counting direction. If clear, direction is forward or up. If set, the direction is reverse or down.
• Bits 10 “SmplRate bt0” -12 “SmplRate bt2” configure the Finite Impulse Response (FIR) Filter (see Table 259A: FIR Filter Settings
). This setting reduces the effect of noisy feedback on the system.
Refer to the Speed/Position Feedback section of the PowerFlex® 700S with Phase II Control Reference Manual, publication PFLEX-RM003 for details.
Notes: Bit 11 “SmplRate bt1” is set to 0 = False by default for firmware version 1.11 and is set to 1 = True by default for firmware version 2.003. This parameter was changed to non-linkable for
firmware version 3.001.
260 Stegmann0 Status
Indicates faults on the Stegmann Hi-Resolution Encoder Feedback Option.
• Bit 8 “Open Wire” indicates an open wire fault.
The feedback option card checks for a pre-determined constant value. If this value is not within tolerances, an open wire fault is declared. A quadrature check also is done. If an error occurs during
the check, the ope wire check is aborted. If 3 quadrature errors occur in succession, the open wire check will complete and the constant value checked again. If this value is not within tolerances,
the fault is declared.
• Bit 9 “PowerSup Er” indicates the failure of the power supply.
• Bit 10 “PwrUpDiag Er” indicates the option board failed its power-up diagnostic test.
The pattern on the FPGA must be identical to the pattern written from the DSP, or the board status test will fail.
• Bit 11 “MsgChksum Er” indicates a message checksum fault.
The check sum associated with the Heidenhain encoder must be correct and acknowledged by the feedback option card.
• Bit 12 “Time Out Err” indicates a RS-485 time-out fault.
This check requires information to be sent from the encoder to the feedback option card within a specified time. Typical times are about 10 clock cycles before an error is detected. This check is
done only at power-up.
261 Steg&Hiedn TPSel
Selects data displayed by Par 262 [Steg&Hiedn TPDta].
• Hh0 Edge Time - Latency counter value, not used for Hi-Resolution Feedback Option.
• Hh0 dEdge - Change in edge counts for one 500 microsecond update. At constant speed, this value should be
constant.
• Hh0 dTime - Change in update time. This value should be constant, 500 microseconds.
• Hh0 EPR - This value should be 1,048,576 counts per revolution-this is a constant value.
• Hh0 nMax - This is a scaled value of 2.
• Hho Delta2Err - Derivative of value 2.
Default:
Options:
0 =
0 =
1 =
2 =
3 =
4 =
5 =
6 =
7 =
8 =
9 =
“Zero”
“Zero” 10 = “Reserved”
“St0 EdgeTime” 11 = “Hh0 EdgeTime”
“St0 dEdge” 12 = “Hh0 dEdge”
“St0 dTime” 13 = “Hh0 dTime”
“St0 EPR” 14 = “Hh0 EPR”
“St0 EdgeMode” 15 = “Hh0 EdgeMode”
“St0 nMax” 16 = “Hh0 nMax”
“St0 Delta2Er” 17 = “Hh0 Delta2Er”
“Reserved”
“Reserved”
262 Steg&Hiedn TPDta
Displays data selected by Par 260 [Stegmann0 Status].
Default:
Min/Max:
0
-/+32768
RO 16-bit
Integer
No. Name
Description
Values
Linkable Read-Write Data Type
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved SmplRate bt2 SmplRate bt1 SmplRate bt0 Reserved Reserved Reserved SW Reset Direction Reserved Reserved Reserved Reserved Reserved
Default xxxxxxxxxxxxxxxxxxx000xxx00xxxxx
Bit 313029282726252423222120191817161514131211109876543210
0 = False
1 = True
Table 259A: FIR Filter Settings
Bit 12 11 10 Taps
0001
0012
0104
0118
10016
10132
11064
111127
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Time Out Err MsgChksum Er PwrUpDiag Er PowerSup Er Open Wire Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved
Default xxxxxxxxxxxxxxxxxxx00000xxxxxxxx
Bit 313029282726252423222120191817161514131211109876543210
0 = False
1 = True
