Rockwell Automation Allen-Bradley Ultra3000 User Manual

26 Rockwell Automation Publication 2198-RM006A-EN-P - December 2020
Chapter 2 Servo Drive and System Comparisons
Figure 5 - Kinetix 5300 Drives with Connector Kit Accessories (Frames 2 and 3)
265
(10.43)
65.0
(2.56)
265
(10.43)
65.0
(2.56)
100
(3.94)
48
(1.89)
300
(11.81)
248
(9.76)
80
(3.15)
Dimensions are in mm (in.)
2198-K53CK-D15M Feedback
Connector Kit Mounted on
Kinetix 5300 Frame 2 Drive
2198-K53CK-D15M Feedback
Connector Kit Mounted on
Kinetix 5300 Frame 3 Drive
2090-CFBM7DD-CEAxxx
Feedback Cable
(drive-end connector)
2090-CTFB-MxDD
Feedback Cable
Clearance required for drive-end cable
connectors apply to all frame sizes.
Frame 3 clamping plate for
large diameter cables.

Rockwell Automation Allen-Bradley Ultra3000 Specifications

General

Brand	Rockwell Automation
Model	Allen-Bradley Ultra3000
Category	Servo Drives
Language	English
