Rockwell Automation Publication 2198-RM006A-EN-P - December 2020 63
Appendix C Specifications
Control and Auxiliary Power
Specifications
This section provides the control and auxiliary power specifications for the
Ultra3000 and Kinetix 5300 servo drives.
Ultra3000 Servo Drive Auxiliary Power Specifications
Table 47 - Ultra3000 Drives +24V Power Supply Requirements for Logic Power
Table 46 - Kinetix 5300 (480V, three-phase) Input Power Specifications (continued)
Attribute 2198-C4030-ERS 2198-C4055-ERS 2198-C4075-ERS
AC input voltage 342…528V rms, three-phase (480V nom)
AC input frequency 47…63 Hz
Main AC input current (rms)
(1)
9.06 A 17.50 A 21.29 A
Max inrush current (0-pk) 30.9 A 30.9 A 46.4 A
Peak AC input current (rms) 23.07 A 39.57 A 49.72 A
Control power input voltage
(2)
21.6…26.4V DC
24V DC nom
Control power input current
(1)
(3)
(non-brake motors)
0.9 A
DC
1.7 A
DC
1.7 A
DC
Continuous output current (rms) 11.7 A 22.6 A 27.5 A
Continuous output current (0-pk) 16.5 A 32.0 A 38.9 A
Peak output current (rms)
(4)
34.1 A 58.5 A 73.5 A
Peak output current (0-pk) 48.3 A 82.7 A 103.9 A
Line loss ride through 20 ms
Continuous output power 6.25 kW 12.08 kW 14.70 kW
Internal shunt on 775V
Internal shunt off 765V
Internal shunt resistor 60 Ω 40 Ω
Internal shunt power 50 W 75 W
Bus undervoltage limit 275V
Bus overvoltage limit 810V
Bus capacitance 560 µF 820 µF 1230 µF
Capacitive energy absorption 27.59 J 40.40 J 60.60 J
Efficiency 97%
Short-circuit current rating 200,000 A (rms) symmetrical
(1) Drives are limited to one power cycle per minute.
(2) The cooling fan runs as part of the control power startup routine, when the inverter is enabled, and if the inverter temperature exceeds preset threshold.
(3) For current values when motors include a holding brake, refer to Kinetix 5300 Servo Drive Control Power Specifications
.
(4) Peak RMS current allowed for up to 1.0 seconds.
Parameter Description Min Max
Input voltage range
Input voltage range of the external power supply for
drive-mounted breakout boards with 24V to 5V
converter.
18V 30V
Input current
Input current draw from the external power supply for
the drive-mounted breakout boards with 24V to 5V
converter.
—400 mA
IMPORTANT
A 24V power supply can be used to power the digital I/O and supply 24V
to the drive-mounted breakout boards (catalog numbers 2090-U3CBB-
DMxx) provided the cumulative minimum current requirements are met.
