PowerFlex Digital DC Drive User Manual - Publication 20P-UM001C-EN-P - July 2008
Supplemental Drive Information A-3
Feedback
Devices
Encoder Type: Incremental, dual channel, two channel optional
(with jumper), differential (recommended) or
single-ended
Input Voltage: Configurable for +2.5V - 5.2V (switch S21
in ENC_5 position) or +5.4V - 15.2V (switch S21 in
ENC_12 position)
Input Current: 4.5 mA / 6.8 - 10.9 mA each channel
Quadrature: 90° ± 27° @ 25°C
Duty cycle: 50% ± 10% Source/Sink capable
Pulses Per Revolution: 600 to 9999
Maximum Frequency: 150 kHz
Maximum Cable Length: Shielded, 150m (0.75 mm
2
),
125m (0.5 mm
2
), 55m (0.22 mm
2
)
DC Analog Tachometer Input Voltage: 22.7, 45.4, 90.7, 181.6, & 302.9V max.
Input Current: 8 mA full scale
Maximum Cable Length: Shielded, depends on the
installation, typical 150m.
Inputs Analog Inputs Three configurable, isolated, differential
±10V, 0-10V, 0-20mA or 4-20mA.
Digital Inputs Eight standard configurable, four additional configurable
with the I/O Expansion circuit board.
Max Voltage +30V DC input, 200mA (total current draw is
the sum of encoder power, digital outputs and any other
loads connected to terminal 19)
Outputs Analog Outputs Two standard configurable, two additional configurable
with the I/O Expansion circuit board. Sampling rate 2 ms.
± 10V, 5mA, bipolar (current is not bipolar)
Digital Outputs Four standard configurable, four additional configurable
with the I/O Expansion circuit board.
+ 30V, 50mA
Relay Outputs Two configurable, N.O. contacts
Max. 250V AC, 1A AC1
Category Specification
