PowerFlex Digital DC Drive User Manual - Publication 20P-UM001C-EN-P - July 2008
D-24 Control Block Diagrams
Fault / Alarm Mapping
“Motor Over Temp” (F16)
“Auxiliary Input” (F2)
“Arm Overvoltage” (F5) “Fld Current Loss” (F6)
“Encoder Loss” (F91)
Fault/Alarm Mapping
P203
OverVolt Flt Cfg
P365
OverTemp Flt Cfg
P354
Aux Inp Flt Cfg
P473
FldLoss Flt Cfg
P478
Spd Loss Flt Cfg
0 = “Ignore”
1 = “Alarm”
2 = “Fault”
0 = “Ignore”
1 = “Alarm”
2 = “Fault”
3 = “Quick Stop”
4 = “Normal Stop”
5 = “CurrLim Stop”
1 = “Alarm”
2 = “Fault”
3 = “Quick Stop”
4 = “Normal Stop”
5 = “CurrLim Stop”
0 = “Ignore
”
1 = “Alarm”
2 = “Fault”
1 = “Alarm”
2 = “Fault”
