PowerFlex Digital DC Drive User Manual - Publication 20P-UM001C-EN-P - July 2008
Installation and Wiring 1-21
Figure 1.16 Frame C Armature Converter Terminal Block Location
UCVDW
PE
Bottom View
Front View
