Roland Quad-Capture User Manual

Recording
Flowchart: Using the QUAD-CAPTURE for Recording
DAW (Digital Audio Workstation) is the generic term used for music creation software.
Install the driver (p. 14).
Windows/Mac OS X
Prepare the DAW software,
such as Ableton Live,
GarageBand, Logic, etc.
Yes. No.
Set the input/output audio device on the DAW (p. 24, p. 27).
Connect a guitar or microphone to the QUAD-CAPTURE (p. 25).
Adjust the input gain level.
QUAD-CAPTURE (p. 25)
Control panel (p. 29)
Adjust the preamp or compressor
(p. 29, p. 30).
Do you have a DAW?

Roland Quad-Capture Specifications

General

Audio Resolution	24-bit/192 kHz
USB	USB 2.0
MIDI	In/Out
Direct Monitoring	Yes
Type	Audio Interface
Preamps	2x VS Preamps
OS Compatibility	Windows, macOS
Inputs	2x XLR/TRS combo
Phantom Power	Yes (48V, switchable on inputs 1-2)
Channels	4
Driver	ASIO, Core Audio
Dimensions	185 mm x 134 mm x 44 mm / 7-5/16 inches x 5-5/16 inches x 1-3/4 inches
