Roland Quad-Capture User Manual

27
Basic Use
Input Device Settings
To record audio and MIDI data on your DAW software, select the QUAD-CAPTURE as the audio and
MIDI input device. For details about settings, refer to the documentation for your DAW software.
Audio Input Device
Device name
MME,
WDM/KS
ASIO Core Audio
44.1 kHz–
96 kHz
192 kHz
QUAD-CAPTURE
1-2
(QUAD-CAPTURE)
1-2 1, 2
✓ ✓
3-4
(QUAD-CAPTURE)
3-4 3, 4
✓
MAIN
(QUAD-CAPTURE)
MAIN 5, 6
✓
MIDI Input Device
Device name
QUAD-CAPTURE

Roland Quad-Capture Specifications

General

Audio Resolution	24-bit/192 kHz
USB	USB 2.0
MIDI	In/Out
Direct Monitoring	Yes
Type	Audio Interface
Preamps	2x VS Preamps
OS Compatibility	Windows, macOS
Inputs	2x XLR/TRS combo
Phantom Power	Yes (48V, switchable on inputs 1-2)
Channels	4
Driver	ASIO, Core Audio
Dimensions	185 mm x 134 mm x 44 mm / 7-5/16 inches x 5-5/16 inches x 1-3/4 inches
