28
Setting from the Control Panel
You can control the AUTO-SENS setting via the QUAD-CAPTURE’s control panel, which is installed on
the computer. The QUAD-CAPTURE control panel also provides for control of the QUAD-CAPTURE’s
internal preamps, compressor, input mixer, and DIGITAL OUT SELECTOR.
You cannot control any function other than input gain of the preamp and the AUTO-SENS setting
using the QUAD-CAPTURE itself.
The control panel will be available for use after you’ve installed the dedicated driver. For more about
using the control panel, you can also select “Show README” from the QUAD-CAPTURE control panel.
Windows version From the [Driver] menu, select [Show README].
Mac OS X
version
From the [QUAD-CAPTURE Control Panel] menu, select [Show README].
Direct mixer
OUTPUT
1L/2R
COAXIAL
OUT (3/4)
PHONES
INPUT 1L
INPUT 2R
COAXIAL IN
(3/4)
WAVE IN
WAVE OUT
1–4
1–4
1–2
5–6
1–4
INPUT
MIXER
DIGITAL OUT
SELECTOR
Starting up the Control Panel
Access the QUAD-CAPTURE control panel as follows.
Windows
Open the “Control Panel” and double-click the [QUAD-CAPTURE] icon.
If you don’t see the QUAD-CAPTURE icon, switch to Icon view (Windows 8.1/8/7) or Classic view
(Windows Vista/Windows XP).
Mac OS X
Open the [Applications] folder, then double-click [QUAD-CAPTURE Control Panel].
