Roland Quad-Capture User Manual

35
Setting from the Control Panel
Checking the Driver Settings
You can check or modify the driver settings. For details, refer to “Advanced Driver Settings” (p. 51).
Windows
From the “Driver” menu, select [Driver Settings].
Mac OS X
From the “QUAD-CAPTURE Control Panel” menu, select [Driver Settings].
Viewing the Control Panel in the Foreground
You can set the software so the QUAD-CAPTURE control panel always appears in the foreground.
Windows
From the “Driver” menu, select [Always on top].
Mac OS X
From the “QUAD-CAPTURE Control Panel” menu, select [Always on top].
Checking the Version of the Control Panel
You can check the version of the control panel.
1. Select the “About Driver & Control Panel” menu.

Roland Quad-Capture Specifications

General

Audio Resolution	24-bit/192 kHz
USB	USB 2.0
MIDI	In/Out
Direct Monitoring	Yes
Type	Audio Interface
Preamps	2x VS Preamps
OS Compatibility	Windows, macOS
Inputs	2x XLR/TRS combo
Phantom Power	Yes (48V, switchable on inputs 1-2)
Channels	4
Driver	ASIO, Core Audio
Dimensions	185 mm x 134 mm x 44 mm / 7-5/16 inches x 5-5/16 inches x 1-3/4 inches
