Roland Quad-Capture User Manual

54
Main Specications
Connectors
Input jacks 1–2
XLR type (balanced, phantom power: +48 V, 6mA Max)
* Current value per channel.
1/4-inch TRS phone type (balanced)
* INPUT 1 supports high impedance
Headphones jack (Stereo 1/4-inch phone type)
OUTPUT jacks 1–2 (1/4-inch TRS phone type (balanced))
COAXIAL IN connector
COAXIAL OUT connector
MIDI connectors (In, Out)
USB connector
Interface
USB 2.0 (Hi-Speed)
Digital input/output Coaxial type (conforms to IEC60958)
MIDI IN/OUT
Power Supply USB Bus Power
Current Draw 480 mA
Dimensions
184.6 (W) x 133.9 (D) x 44.3 (H) mm
7-5/16 (W) x 5-5/16 (D) x 1-3/4 (H) inches
Weight 0.57 kg / 1 lb 5 oz.
Accessories
Owner’s Manual
Driver CD-ROM
USB cable
Ableton Live Lite Serial Number Card
(0 dBu=0.775 Vrms)
* In the interest of product improvement, the specications and/or appearance of this unit are
subject to change without prior notice.

Roland Quad-Capture Specifications

General

Audio Resolution	24-bit/192 kHz
USB	USB 2.0
MIDI	In/Out
Direct Monitoring	Yes
Type	Audio Interface
Preamps	2x VS Preamps
OS Compatibility	Windows, macOS
Inputs	2x XLR/TRS combo
Phantom Power	Yes (48V, switchable on inputs 1-2)
Channels	4
Driver	ASIO, Core Audio
Dimensions	185 mm x 134 mm x 44 mm / 7-5/16 inches x 5-5/16 inches x 1-3/4 inches
