110
Detailed Settings for Each Function ([EDIT] Button)
This setting determines whether or not the MIDI messages
necessary to synchronize the RD-700GX with external devices
are to be transmitted from the MIDI OUT connector.
You can switch the RD-700GX’s Setups with MIDI messages
from an external MIDI device.
Set the MIDI Receive channel for receiving the MIDI messages
(Program Changes) from the external MIDI device to be used
for switching Setups.
When not switching Setups from an external MIDI device, set
this to OFF.
When the SETUP Control Channel settings are
transmitted along with the part’s MIDI receive
channel (p. 127), switching of Setups takes priority
over the switching of tones.
For more information about Switching Setups, refer
to “Switching Setups” (p. 140).
The Device ID number is an identification number used when
transmitting and receiving MIDI Exclusive messages. When
transmitting Exclusive messages, the device ID numbers of the
corresponding devices must be matched.
Refer to the “Switching USB Drivers” (p. 142)
Refer to the “Changing the USB Memory Setting” (p. 142)
Refer to the “Using the RD-700GX as a USB MIDI Interface
(USB MIDI Thru Sw)” (p. 142)
This setting specifies the function of the RD-700GX’s MIDI
THRU/OUT 3 connector.
If you choose “OUT,” the connector will function as MIDI OUT,
and will transmit data from the keyboard and controllers to an
external MIDI device.
If you choose “THRU,” the connector will function as MIDI
THRU, retransmitting without change the MIDI messages that
are received at the MIDI IN connector. Performance data from
the RD-700GX itself will no longer be sent from this connector.
Transmitting Synchronization
Messages (Clock Out)
Parameter
Value
Clock Out
ON, OFF
Using Program Change Messages to
Switch Setups (SETUP Control Channel)
Parameter
Value
SETUP Ctrl Ch
(SETUP Control Channel)
1–16, OFF
Setting the Device ID Number
(Device ID)
Parameter
Value
Device ID
17–32
NOTE
Selecting the USB Driver (USB Driver)
Switching the USB Memory Mode
(USB Memory Mode)
Selecting the USB MIDI Thru Switch
(USB MIDI Thru Switch)
Selecting the Function of the MIDI
THRU/OUT 3 Connector
(MIDI OUT3 Mode)
Parameter
Value
MIDI OUT3 Mode
THRU, OUT
RD-700GX_e.book 110 ページ ２００８年２月１３日 水曜日 午後５時４９分
