AC-015 Hardware Installation and Programming Manual 11
2. Technical Specifications
2.1 Electrical Characteristics
2.1.1 Main Unit
Operating Voltage
16 VAC (1.5 A, 25 VA)
From a transformer
Maximum Input Current
(not including attached
devices)
Standby: 65 mA
Maximum: 120 mA
Battery Charger
12 VDC Lead Acid Battery
Up to 7 AH recommended
2.1.2 Outputs
Lock Strike Relay Output
5 A Relay
Lock Strike Power Supply
12 VDC constant voltage
1.2 A current limit
N.O. or N.C. option
Tamper Relay Output
1 A Relay N.C. Dry Contact
Reader Power Supply
Voltage: 12 VDC
Max Current: 300 mA
2.1.3 Inputs
REX
N.O. Dry Contact
Two Reader Inputs
Wiegand 26-Bit compatible
2.1.4 Indicators and Annunciators
Visual
Two tri-colored LEDs
Audio
Built-in sounder (bell, chime & siren)
Piezoelectric buzzer
